Bosch Blaze laser measures offer precision and efficiency for various tasks. These tools, like the GLM400CL, feature cameras and viewfinders for enhanced targeting.
What is a Bosch Blaze Laser Measure?
Bosch Blaze laser measures are digital distance-measuring tools utilizing laser technology for quick, accurate results. Models like the GLM 20, 40, 42, 400C, and 400CL cater to diverse needs, from basic indoor measurements to complex outdoor calculations. They simplify tasks for professionals and DIY enthusiasts alike.
These devices offer features like full-color displays, integrated cameras (GLM400CL), and Bluetooth connectivity via the Bosch MeasureOn app, streamlining data transfer and documentation.
Key Features and Benefits
Bosch Blaze laser measures boast several key advantages. Accurate measurements up to 400ft are achievable, especially with models like the GLM400CL, featuring a 5.0 megapixel camera for target identification. The integrated viewfinder aids in sunlight visibility.
Benefits include increased efficiency, reduced errors, and simplified documentation through Bluetooth connectivity and the Bosch MeasureOn app. Full-color backlit displays ensure readability in various lighting conditions, enhancing usability.
Understanding Your Bosch Blaze Model
Bosch Blaze models, including GLM 20, 40, 42, 400C, and 400CL, offer diverse features. Identifying your specific model is crucial for utilizing its capabilities effectively.
Identifying Your Specific Model (GLM 20, 40, 42, 400C, 400CL)
Bosch Blaze laser measures come in several variations, each designed for specific needs. The GLM 20 is a basic, compact model, while the GLM 40 offers an extended range. The GLM 42 boasts a full-color backlit display for improved visibility. For outdoor use, the GLM 400C includes a viewfinder, and the GLM 400CL adds a 5.0-megapixel camera with 8x zoom for precise target location, even in sunlight. Checking the model number, typically located on the device’s back or battery compartment, ensures you access the correct manual and features.
Package Contents
Upon opening your Bosch Blaze laser measure package, verify all components are present. Typically, you’ll find the laser measure itself, a wrist strap for secure handling, and a quick start guide for initial setup. Some models, like the 400C/400CL, may include a USB cable for data transfer and charging. Always retain the original packaging for potential warranty claims or returns. Refer to the included documentation to confirm the specific contents for your particular model.
Getting Started: Basic Operation
Bosch Blaze laser measures are user-friendly. Power on using the designated button, understand the display, and select your preferred unit – feet, meters, or inches.
Powering On and Off
To activate your Bosch Blaze laser measure, locate the clearly marked power button – typically found on the side or top of the device. A single press will initiate the tool, displaying the battery level and readiness indicator. For deactivation, press and hold the same power button for a few seconds until the display turns off.
Ensure the device is completely powered down when not in use to conserve battery life and prevent accidental measurements. Some models feature an auto-off function for added convenience and energy saving.
Understanding the Display
The Bosch Blaze laser measure’s display provides crucial information. Expect to see the measurement reading, unit of measurement (feet, meters, inches), battery status indicator, and Bluetooth connectivity status if applicable. Models like the GLM 42 boast full-color backlit displays for enhanced visibility in low-light conditions.
Icons indicate functions like continuous measurement or memory recall. Familiarize yourself with these symbols for efficient operation and accurate readings.
Selecting Measurement Units (Feet, Meters, Inches)
To change measurement units on your Bosch Blaze laser measure, typically a dedicated button allows cycling through options. Press the unit selection button repeatedly to toggle between feet, meters, and inches. The currently selected unit is clearly displayed on the device’s screen.
Ensure the correct unit is chosen before taking measurements for accurate results. Refer to your specific model’s manual for precise button locations and operation details.
Detailed Measurement Functions
Bosch Blaze laser measures excel at single, continuous, and indirect measurements—height and width—providing versatile solutions for diverse project requirements and accuracy.
Single Measurements
Bosch Blaze laser measures simplify obtaining quick, precise distances. To perform a single measurement, activate the device and aim the laser dot at the desired target. Press the measurement button; the display instantly shows the distance. This function is ideal for straightforward tasks like room dimensions or material lengths. Ensure a clear laser line for optimal accuracy. The tool automatically stores the last measurement for easy recall, streamlining workflow and minimizing repeated measurements. Consistent, reliable results are guaranteed with each press of the button.
Continuous Measurement
Bosch Blaze laser measures offer a continuous measurement mode for dynamic tracking. Activate this function, and the device constantly updates the displayed distance as you move the laser point. This is exceptionally useful for monitoring changes in distance, like tracking material unrolling or assessing varying heights. The real-time updates provide immediate feedback, enhancing efficiency. Hold the measurement button to initiate, and release to lock the final reading. This feature streamlines tasks requiring ongoing distance monitoring and adjustments.
Indirect Measurements (Height, Width)
Bosch Blaze laser measures excel at indirect measurements, calculating height and width using Pythagorean theorem. Input the horizontal distance and angle, and the device computes the height. For width, measure two distances and the angle between them. These functions eliminate the need for climbing or manual calculations, improving safety and accuracy. Consult your model’s manual for specific button sequences to activate these features. This capability expands the tool’s versatility beyond simple linear distances.
Advanced Features & Specific Models
Bosch Blaze models like GLM 400C/400CL boast viewfinders and cameras. Bluetooth connectivity with the Bosch MeasureOn app enhances data management.
GLM 400C/400CL: Viewfinder & Camera Functionality
The Bosch Blaze GLM 400C and GLM 400CL models distinguish themselves with integrated viewfinder and camera capabilities. The GLM400CL specifically features a 5.0-megapixel camera with 8x digital zoom, enabling users to quickly and accurately pinpoint the laser dot, even at distances up to 400 feet.
This is particularly useful in brightly lit environments or outdoors where the laser beam might be difficult to see. The camera captures an image of the target, simplifying the measurement process and reducing errors. The viewfinder on the 400C provides a direct visual aid for aiming.
Bluetooth Connectivity & Bosch MeasureOn App
Certain Bosch Blaze models, like the GLM 400C/400CL, offer Bluetooth connectivity, seamlessly integrating with the Bosch MeasureOn app. This app, available for smartphones and tablets, allows for wireless data transfer of measurements. Users can easily document, organize, and share measurements directly from the tool.
The app also facilitates creating floor plans, reports, and calculations, enhancing productivity. Real-time data transmission ensures accuracy and eliminates manual transcription errors, streamlining workflows for professionals and DIY enthusiasts alike.
Memory Functions: Saving and Recalling Measurements
Bosch Blaze laser measures incorporate memory functions, enabling users to store multiple measurements for later use. This feature is invaluable for projects requiring numerous readings, eliminating the need for manual note-taking. Stored data can be easily recalled and reviewed on the device’s display.
Specific models, particularly those with app connectivity, allow transferring saved measurements to the Bosch MeasureOn app for more comprehensive documentation and analysis, enhancing project organization and accuracy.
Safety Precautions & Warnings
Bosch Blaze laser measures require caution; avoid direct eye exposure to the laser beam. Never allow unsupervised use by children, as eye injury could occur.
Laser Safety Class and Precautions
Bosch Blaze laser measures are typically Class 2 laser products. This means the laser emits visible light, and blink reflexes generally provide adequate protection. However, avoid staring directly into the laser beam.
Do not disassemble or modify the device, as this could result in hazardous laser radiation exposure. Always adhere to all provided instructions to prevent accidental dazzling or potential eye damage. Ensure the device is used responsibly and kept out of reach of children without supervision.
General Safety Instructions
Bosch Blaze laser measures require careful handling. Always read all instructions before operation to minimize risks. Never aim the laser beam at people or animals. Avoid using the tool in explosive atmospheres or near flammable materials.
Ensure a stable working position and secure the device when necessary. Do not operate the tool if damaged. Save all warnings and instructions for future reference, and always be aware of the laser’s location during use.
Troubleshooting Common Issues
Bosch Blaze may display error codes; consult the manual for meanings. Accuracy issues could require calibration, while battery problems need attention.
Error Codes and Their Meanings
Bosch Blaze laser measures utilize error codes to indicate specific problems. A common issue involves low battery, prompting replacement or recharge. Other codes may signal measurement errors, often due to obstructions or reflective surfaces. The official manual details each code’s precise meaning, guiding users toward solutions. For instance, a “E0” code often indicates a calculation error, while “E1” suggests a ranging problem. Always refer to the manual for accurate diagnosis and troubleshooting steps to ensure optimal performance and prevent inaccurate readings.
Accuracy Issues and Calibration
Bosch Blaze laser measures offer high precision, but accuracy can be affected by environmental factors or misuse. If measurements seem inconsistent, verify proper technique and a stable surface. The manual doesn’t detail user calibration; these tools are factory calibrated. However, significant deviations suggest a potential malfunction requiring service. Contact Bosch support for assistance if accuracy remains a concern. Regular maintenance, like cleaning the lens, helps maintain optimal performance and reliable readings over time.
Maintenance and Care
Bosch recommends cleaning the device with a soft cloth. Proper battery management, including timely replacement, ensures optimal performance and extends the tool’s lifespan.
Cleaning the Device
Bosch advises using only a soft, dry cloth to clean the exterior of your Blaze laser measure. Avoid harsh chemicals or abrasive cleaners, as these can damage the housing or lens. Gently wipe away dust and debris from the display and measurement surfaces.
Do not immerse the device in water or any other liquid. For stubborn dirt, slightly dampen the cloth with water, ensuring no moisture enters the internal components. Always dry the device thoroughly after cleaning to prevent corrosion or malfunction. Regular cleaning maintains accuracy and extends the tool’s life.
Battery Management & Replacement
Bosch Blaze laser measures typically utilize standard AA batteries. To maximize battery life, use high-quality alkaline batteries and remove them when the device is not in use for extended periods. Avoid mixing old and new batteries, or different battery types.
When replacing batteries, ensure correct polarity as indicated in the battery compartment. Dispose of used batteries responsibly, following local regulations. Refer to the Bosch rechargeable lithium-ion battery pack manual for specific details if applicable.
Downloading the Manual & Resources
Bosch provides downloadable manuals in PDF format for Blaze models like the GLM 20. Access these and FAQs on the official Bosch support website.
Locating the Official Bosch Blaze Manual (PDF)
Bosch makes accessing your Blaze laser measure’s manual straightforward. Visit the official Bosch Power Tools website and navigate to the support section. There, you can search for your specific model – GLM 20, 40, 42, 400C, or 400CL – to find the corresponding PDF manual.
These downloadable manuals, like the GLM 20 instruction manual (1.4 MB), provide detailed operating instructions, safety precautions, and troubleshooting guidance. Ensure you download the manual relevant to your exact Bosch Blaze model for accurate information.
Bosch Support Website & FAQs
The official Bosch Power Tools support website is a valuable resource beyond just manuals. It features a comprehensive FAQ section addressing common user questions about Blaze laser measures. You’ll find solutions to typical issues, guidance on battery management, and details regarding the limited warranty.
For personalized assistance, Bosch provides contact information for their customer support team. This website offers troubleshooting tips and resources to maximize your laser measuring experience.
Warranty Information
Bosch offers a limited warranty on Blaze laser measures, covering defects in materials and workmanship. Return the complete Bosch laser for a claim.
Bosch Limited Warranty Details
Bosch provides a limited warranty against defects in materials and workmanship for its Blaze laser measures. This warranty doesn’t cover damage from misuse, accidents, or unauthorized repairs. To initiate a claim, return the complete Bosch laser tool, transportation prepaid, to a Bosch Factory Service Center.
The warranty period varies by model; consult your product documentation. This warranty gives specific legal rights, and other rights may exist depending on local laws. See the full warranty details within the product manual or on the Bosch website for complete coverage information.
Contacting Bosch Customer Support
For assistance with your Bosch Blaze laser measure, reach out to Bosch Customer Support. Visit the official Bosch Support website for FAQs, troubleshooting guides, and contact information. You can typically find phone numbers and email addresses for dedicated support teams.
Alternatively, explore online forums and communities where users share experiences and solutions. Refer to your product manual for specific contact details relevant to your region and model. Bosch aims to provide prompt and helpful assistance to all customers.
Technical Specifications
Bosch Blaze models boast varying measurement ranges, typically up to 400 ft, with accuracy within ±1/32 in. Specifications depend on the specific GLM model.
Measurement Range
Bosch Blaze laser measures offer diverse measurement ranges to suit different project needs. The GLM 20 typically measures up to 65 feet, while the GLM 40 and 42 extend to 120 feet. For outdoor applications, the GLM 400C and 400CL provide an impressive range of up to 400 feet.
These ranges enable accurate measurements for both interior and exterior projects, from room dimensions to building heights. Always consult your specific model’s manual for precise range details and optimal performance.
Accuracy
Bosch Blaze laser measures are renowned for their high degree of accuracy, crucial for professional and DIY projects alike. Standard models, like the GLM 20, boast an accuracy of ±1/32 inch. The GLM 400C/400CL maintains a similar accuracy level at typical distances.
However, accuracy can be influenced by factors like surface reflectivity and environmental conditions. Refer to your device’s manual for detailed specifications and calibration guidance to ensure optimal measurement precision.
Accessories & Compatibility
Bosch Blaze laser measures work with compatible tripods and mounts for stability. Optional accessories, like pouches, enhance portability and protection during use.
Compatible Tripods and Mounts
Bosch offers a range of tripods specifically designed for use with Blaze laser measures, ensuring stable and accurate measurements. These tripods often feature quick-adjust height settings and durable construction. Universal tripod mounts are also compatible, allowing users to adapt existing equipment. Consider models with adjustable heads for optimal positioning. Utilizing a tripod minimizes hand shake and improves precision, especially for longer distances or indirect measurements. Proper mounting enhances the overall reliability and efficiency of your Bosch laser tool.
Optional Accessories
Enhance your Bosch Blaze experience with optional accessories! Protective cases safeguard your device during transport and storage. Bosch offers laser targets for improved visibility in bright conditions. Rechargeable batteries provide extended runtime, eliminating reliance on disposables. Calibration certificates ensure continued accuracy. Consider a wrist strap for secure handling. Explore the Bosch website for a complete catalog of compatible accessories designed to maximize the functionality and longevity of your laser measuring tool.
